Defend against threats by analyzing entire systems.

To understand a missile’s capabilities or plan an effective missile defense, you need to look at the whole picture. From a single engagement to an entire campaign, modeling the full operational environment is critical to effective system engineering, test, and operations.

One of the fastest growing threat technologies is hypersonics. With vehicles this fast, you can’t rely on a single sensor. You have to model the full network of ground, air, and space-based detection, tracking, and C2 assets.

With AGI software you can model the full system of systems in a realistic operational environment to make critical engineering and mission planning decisions. Import standard data models or design your own missile models. Evaluate parabolic and hypersonic trajectories in physics-based, high-fidelity simulations. Extend your models from land to space, including direct ascent ASAT trajectories. See the big picture, without losing sight of the details, and respond to any kind of missile threat, anywhere.

Need more information?

Use Cases

Defend Against Threats

  • Simulate threats and intercepts with 6-DOF modeling
  • Evaluate air, space, and ground launches
  • Quantify detection and response chains
  • Ensure communications through complex networks
  • Perform large-scale trade studies

Assess Space Threats

  • Analyze target and chase combinations
  • Provide insight to vulnerabilities
  • Prioritize potential threats
  • Model orbit propagation and maneuvers with precision

Detect Targets

  • Simulate detection, tracking, and imaging performance of EOIR sensors
  • Define low-level sensor parameters
  • Model time dynamic target signatures
  • Produce synthetic scenes
  • Include atmosphere and cloud effects

Featured Product

Image from STK Missile Tool Kit, ICBM

STK Missile Tool Kit

Simulate powered missile trajectories, intercept engagements, and defense system performance.

Related Products

STK EOIR

Model electro-optical and infrared sensor performance.

STK Aviator Pro / Prop Nav

Add guidance strategies, rotorcraft models, and missile models to your STK Aviator repertoire.

STK Aviator

Model real-world flight operations and aircraft performance.

Test and Evaluation Tool Kit (TETK)

Improve the efficiency and effectiveness of test and evaluation activities.

STK Radar

Model and analyze radar systems.

STK Communications

Model and analyze real-world dynamic RF and optical communications.

Moxie

Transform your MBSE artifacts into executable architectures.
